multi-core control cable KVV/KVVR/KVVP

FOB Reference Price:Get Latest Price
US $0.1-1 / Meters | 10000 Meter/Meters (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
ADP&OEM
Model Number:
control cable
Insulation Material:
XLPE
Type:
Medium Voltage
Application:
Construction
Conductor Material:
Copper
Jacket:
PVC, PVC
Conductor:
copper
Insulation:
XLPE
Shileded:
no
Color:
optional
Packaging & Delivery
Packaging Details
1000m with wooden drum or as per your request!
Port
Shenzhen China
Lead Time :
7-12days after received your deposit




   multi-core control cable KVV/KVVR/KVVP



1.Application

The products are suitable for the wiring of electrical  controlling equipments and instrument,monitoring and controlling return circuit,electrical protection and measurement in power distribution unit under the circumstance that the rated voltage is up to 450/750V AC.



2.Operating characteristics:
1).the long-time permissible operating temperature is 70°C
   the ambient temperatrue under installation should not go below 0°C
2)a.for non-armoured cable and flexible shielded cable,the bending radius should not be less than 6 times the outer diameter.

    b.for armoured or copper-tape shielded cable,the bending radius should not be less than 12 times the outer diameter.



3.Type & specification



Modeldescription
KVVCopper conductor PVC insulated PVC sheathed control cable
KVVPCopper conductor PVC insulated PVC sheathed control cable with braided shield
KVVP2Copper conductor PVC insulated PVC sheathed control cable with copper tape shield
KVV22Copper conductor PVC insulated PVC sheathed control cable with steel tape armour
KVV32Copper conductor PVC insulated PVC sheathed control cable with steel wire armour
KVVRCopper conductor PVC insulated PVC sheathed flexible control cable with shield
KVVRPCopper conductor PVC insulated PVC sheathed flexible control cable with braided shield
ZR-KVVCopper conductor PVC insulated PVC sheathed flame retardant control cable
ZR-KVVPCopper conductor PVC insulated PVC sheathed flame retardant control cable with braided shield
ZR-KVVP2Copper conductor PVC insulated PVC sheathed flame retardant control cable with with copper tape shield
ZR-KVV22Copper conductor PVC insulated PVC sheathed flame retardant control cable with with steel tape armour
ZR-KVV32Copper conductor PVC insulated PVC sheathed flame retardant control cable with with steel wire armour
ZR-KVVRCopper conductor PVC insulated PVC sheathed flame retardant flexible control cable
ZR-KVVRP

Copper conductor PVC insulated PVC sheathed flame retardant flexible control cable with braided shield
